Product Summary
The HCPL-263A#500 is an optically coupled gate that combines a GaAsP light emitting diode and an integrated high gain photo detector.
Parametrics
Absolute maximum ratings: (1)Storage Temperature: -55 to 125 ℃; (2)Operating Temperature: -40 to 85 ℃; (3)Average Forward Input Current: 20 mA at Single 8-Pin DIP, Single SO-8, Widebody, 15 mA at Dual 8-Pin DIP, Dual SO-8; (4)Reverse Input Voltage: 5V at 8-Pin DIP, SO-8, 3 V at Widebody ; (5)Input Power Dissipation: 40 mW.
Features
Features: (1)High Speed: 10 MBd Typical; (2)LSTTL/TTL Compatible; (3)Low Input Current Capability: 5 mA; (4)Guaranteed ac and dc Performance over Temperature: -40℃ to +85℃; (5)Available in 8-Pin DIP, SOIC-8, Widebody Packages; (6)Strobable Output (Single Channel Products Only); (7)Safety Approval.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 HCPL-263A#500 |
Avago Technologies |
High Speed Optocouplers 10MBd 2Ch 3mA |
Data Sheet |
|
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
|
HCPL-0201 |
Avago Technologies |
High Speed Optocouplers 5MBd 1Ch 1.6mA |
Data Sheet |
|
|
||||||||||||
|
